Specifications:

Y AXIS: 7.87″ (200 mm)

Z AXIS: 6.3″ (160 mm)

A, B AXIS: INFINITE ROTATION

LASER RESONATOR: IPG

LASER HEAD: PRECITEC (GERMANY)

MAX. POSITIONNING SPEED: 3900″/MIN

POSITIONNING ACCURACY: ±0.03 mm/1000 mm

REPOSITIONNING ACCURACY: ±0.05MM

OTHER FEATURES:

-Supports multiple tube shapes, including round, square, triangular, rectangular, oval, and custom-sized round tubes.

-Automatic tube type recognition system allows loading of multiple different tube types together, unsorted.

-Specially designed flexible tube support device ensures a firm grip on the tube during feeding and rotation.

-COOLING SYSTEM: TEYU CWFL-2000/3000 OR SIMILAR

-EXHAUST FAN

AVAILABLE OPTIONS:

-automatic loading for an entire tube bundle

-160 mm Chuck: Accepts up to 6.3″ diameter (160 mm)

-320 mm Chuck: Accepts up to 12.6″ diameter (320 mm)

-400 mm Chuck: Accepts up to 15.7″ diameter (400 mm)

-500 mm Chuck: Accepts up to 19.7″ diameter (500 mm)
