- Product No : NFRDB -250
- Model : RDB-250
- Type : HYDRAULIC
- Speed : 180° IN 9 SEC.
- Voltage : 220V / 1PH
CAPACITY :
STAINLESS STEEL PIPE (SCH.40) : 48 x 3 MM
ALUMINUM PIPE (SCH.40) : 60 x 4 MM
MILD STEEL PIPE (SCH.40) : 60 x 4 MM
ROUND MILD STEEL TUBE ( WALL ) : 64 x 3 MM
ROUND ALUMINUM TUBE ( WALL ) : 64 x 4 MM
ROUND STAINLESS STEEL TUBE ( WALL ) : 60 X 3 MM
SQUARE MILD STEEL TUBE ( WALL ) : 50 x 3 MM
FULL ROUND MILD STEEL : 32MM
MINIMUM OD : 6MM
MINIMUM CLR : 13MM
MAXIMUM RADIUS CENTER LINE : 229MM
Weight
- 610LBS
